Taw qhia
AC lub zog hluav taws xob muaj qhov zoo ntawm kev ua haujlwm siab, ua tiav kev tiv thaiv kev ua haujlwm, muaj kev ntseeg siab thiab ua haujlwm ntev.
Aqhov zoo
1.Qhov txoj kab nqes los tiv thaiv swb ua haujlwm uas tsis tuaj yeem pom tau los ntawm series excitation hluav taws xob tswj tau pom tau.
2.Battery, lub cev muaj zog ua hauj lwm tam sim no pulsation zoo heev txo, kev cia siab rau thiab kev pab cuam lub neej zoo heev.
3.Xuzhou Forklift yog tshwj xeeb tsim thiab tsim rau series ntawm forklift tsheb. Lub ntsej muag zoo nkauj. Cov khoom siv hluav taws xob tau muab tso rau hauv cov cuab yeej thiab cov cuab yeej siv siab siv. Txhua huab cua tso saib ua rau koj paub qhov xwm txheej ntawm lub tsheb.
Product Detail
Keeb kwm: Jiangsu, Suav teb
Ntawv pov thawj: ISO9001 thiab lwm yam.
Nqe: Negotiable
Lub sij hawm them nyiaj: T / T, L / C
Hnub xa khoom: Negotiable
Packing: export txheem pob
Kev Lag Luam: Middle East / Africa / Asia / South America / Europe / North America
Warranty: 1 xyoo lossis warranty tshwj xeeb cog lus
MOQ: 1 set
Technical Specifications
Hom qauv | Fais Forklift Truck | |||||
Yam khoom No. | CPD 20 | CPD 25 | CPD 30 | |||
Load Capacity | kg | 2000 | 2500 | 3000 | ||
Load Center | mm | 500 | 500 | 500 | ||
Max Lifting Qhov siab | mm | 3000 | 3000 | 3000 | ||
Dawb Lifting Qhov siab | mm | 110 | 110 | 110 | ||
Tilting lub kaum sab xis (Tom ntej / rov qab) | deg | 6/12 | 6/12 | 6/12 | ||
Pem hauv ntej Overhang | mm | 463 | 463 | 485 | ||
Rov qab Overhang | mm | 350 | 350 | 370 | ||
Zuag qhia tag nrho | L (tsis muaj diav rawg) | 2332 | 2332 | 2490 | ||
W | 1177 | 1177 | 1225 | |||
H (tsis muaj mast) | 2215.5 | 2215.5 | 2220 | |||
Min. Tig Radius | mm | 2166 | 2166 | 2220 | ||
Max. Kev ceev ceev (nrog / tsis muaj load) | km/h | 15/14 | 15/14 | 15.5./15 | ||
Max. Lifting ceev (tsis muaj / nrog load) | mm/s | 440/310 | 440/310 | 450/280 | ||
Max. Gradability | % | 15 | 15 | 15 | ||
Qhov hnyav | kg | 4300 | 4300 | 4850 | ||
Log tsheb | Lub log pem hauv ntej | 7. 00-12TT-12PR | 7. 00-12TT-12PR | 28 x 9-15-14PR | ||
Tsheb Tyre | 18 x 7-8TT | 18 x 7-8TT | 18 x 7-8-14PR | |||
Lub log | Pem hauv ntej | 980 | 980 | 1000 | ||
Qab | 945 | 945 | 980 | |||
Log Base | mm | 1500 | 1500 | 1680 | ||
Min. Av clearance | Los ntawm Mast | 135 | 135 | 135 | ||
Hauv qab | 157 | 157 | 157 | |||
Ntev ntawm Fork | m | 1m - 2.5m | ||||
Khoom siv ntawm Sear | Artificial tawv los yog tawv | |||||
Qhov siab ntawm Mast | m | 3m - 5m | ||||
Tyre Hom | Khoom los yog Pneumatic | |||||
Xim | Xiav, liab lossis customized | |||||
Cav | Qauv No. | Roj teeb 48V / 630Ah | Roj teeb 48V / 630Ah | Roj teeb 80V / 480Ah | ||
Rated zog | kws | Tsav lub cev muaj zog | Tsav lub cev muaj zog | Tsav lub cev muaj zog | ||
